2013 Ford E-Series E-350 SD
-
Call for Pricing & Availability Chatham Ford Price
-
Call for Pricing & Availability Chatham Ford Price
Visit our Store
- Chatham Ford Inc
-
781 Main Street
Chatham, MA 02633
- Sales: 774-734-3008
- Service: 774-734-3132
- Parts: 774-734-3007
Vehicle Information
VIN:
1FDWE3FL6DDA36848
Stock #:
3605T
Model Code:
E3F
-
Body Style Commercial/Cutaway/Chassis Van RWD -
Exterior Color White
-
Mileage 0
-
Engine 8 Cyl - 5.4 L -
Transmission 5-Speed Automatic -
Fuel Type Flex Fuel
Eligible Benefits
All Features
- 4.10 axle ratio
- Rear wheel drive
- 120 amp alternator
- 72 amp/hr (650 CCA) maintenance-free HD battery
- Modified vehicle wiring kit & system
- Payload pkg -inc: 10050# GVWR
- HD front/rear shocks
- Pwr steering w/HD steering gear
- Pwr 4-wheel disc brakes
- Auxiliary fuel port
- LT245/75R16E all-season BSW tires
- No spare tire & wheel
- Single rear wheels
- 16" x 7" steel wheels
- Painted black front bumper w/lower black plastic valence
- Sealed beam headlights
- Solar tinted glass
- Interval windshield wipers
- Electronic AM/FM stereo -inc: digital clock, aux input jack & (2) speakers
- Dual high back bucket seats -inc: inboard armrests (REQ: A_ Vinyl or C_ Cloth Trim)
- Medium Flint, Vinyl seat trim (REQ: 211 or 21B Seats)
- Black vinyl floor covering
- Tilt steering wheel
- Medium Flint-color instrument panel -inc: double 12-volt pwr point, tachometer
- Key in ignition warning chime
- Front air conditioning
- Dash sound absorber
- Glove box w/auxiliary pwr point
- Rearview mirror delete
- Medium flint-color door trim panels w/single stowage area
- Driver & passenger black cowl trim panels
- Front vinyl-faced molded headliner
- Dual color-keyed vinyl sunvisors
- Light & convenience group
- Front dome light
- Front door courtesy light switches
- Black plastic step well pads
- Color-keyed cowl grab handles
- 4-wheel anti-lock brakes (ABS)
- Driver & front passenger 2nd generation air bags
- Medium flint-color seat belts w/height adjustable D-ring
- Tire pressure monitoring system (TPMS)
- Dual note horn
5.4L EFI TRITON V8 FFV ENGINE
- (STD)
- Airbags - Front - Dual
- Cold Cranking Amps @ 0° F (Primary): 650
- Maximum Alternator Capacity (amps): 120
- Maximum Alternator Watts: 1620
- Total Cooling System Capacity (qts): 28.3
- Gross Axle Wt Rating - Front (lbs): 4050
- Gross Axle Wt Rating - Rear (lbs): - TBD -
- Curb Weight - Front (lbs): 2814
- Curb Weight - Rear (lbs): 1968
- Gross Vehicle Weight Rating Cap (lbs): 10050
- Gross Combined Wt Rating (lbs): 13000
- Suspension Type - Front: Coil
- Suspension Type - Rear: 1-Stage Multi-Leaf
- Spring Capacity - Front (lbs): - TBD -
- Spring Capacity - Rear (lbs): - TBD -
- Axle Type - Front: Twin I-Beam
- Axle Type - Rear: Full-Floating
- Axle Capacity - Front (lbs): - TBD -
- Axle Capacity - Rear (lbs): - TBD -
- Axle Ratio (:1) - Rear: 4.10
- Shock Absorber Diameter - Front (mm): 35
- Shock Absorber Diameter - Rear (mm): 35
- Stabilizer Bar Diameter - Front (in): 0.91
- Brake Type: Pwr
- Brake ABS System: 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness (in): 13.6 x 0.49
- Rear Brake Rotor Diam x Thickness (in): 13.6 x 0.35
- Front Tire Order Code: T38
- Rear Tire Order Code: T38
- Front Tire Size: LT245/75R16E
- Rear Tire Size: LT245/75R16E
- Front Tire Capacity (lbs): 3042
- Rear Tire Capacity (lbs): 3042
- Revolutions/Mile @ 45 mph - Front: 677
- Revolutions/Mile @ 45 mph - Rear: 677
- Front Wheel Size (in): 16 x 7.0
- Rear Wheel Size (in): 16 x 7.0
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Steering Type: Pwr
- Steering Ratio (:1), On Center: 17.0
- Steering Ratio (:1), At Lock: 17.0
- Turning Diameter - Curb to Curb (ft): 48.6
- Turning Diameter - Wall to Wall (ft): 50.0
- Frame Type: Ladder
- Fuel Tank Capacity, Approx (gal): 40
- Fuel Tank Location: Aft Of Rear Axle
- Wheelbase (in): 138.0
- Length, Overall w/o rear bumper (in): 241.1
- Width, Max w/o mirrors (in): 79.4
- Overhang, Front (in): 30.0
- Overhang, Rear w/o bumper (in): 68.5
- Ground to Top of Frame (in): 20.9
- Frame Width, Rear (in): 42.0
- Ground Clearance, Front (in): - TBD -
- Ground Clearance, Rear (in): - TBD -
- Passenger Capacity: 2
- Front Head Room (in): 42.0
- Front Leg Room (in): 40.0
- Front Shoulder Room (in): 68.1
- Front Hip Room (in): 65.6
- Vehicle Name: Ford Econoline Commercial Cutaway
- Body Style: Chassis Cab
